How would you generate all possible binary trees from a sequence of inputs?

Trees and Binary Trees

First, what even is a binary tree? In computer science, a tree data structure models “one-to-many” relationships. For example, a mother can have multiple children, but a child can have only one (biological) mother. The branch of an actual tree might have many leaves, but any leaf is connected to a single branch. Abstractly, some “nodes” in a tree are “parents” or “branches” to other nodes, their “children” (which can themselves be “parents” or “branches”). Eventually, there are “children” with no children of their own, the “leaves” of the tree.

In a binary tree, a parent has exactly two children. Binary trees are interesting because they are recursively defined, but still very simple. A tree in which parents might have more than two children (an “\(n\)-ary tree”) can always be converted into a binary tree by introducing “intermediate” or “latent” parents. This is related to the fact that context-free grammars can always be converted to Chomsky normal form. For this reason, I’ll be referring to “branch” nodes as “nonterminal” and “leaf” nodes as “terminal.”

Tree data structures are valuable for modeling component-part relationships. Therefore, when we generate “all possible binary trees from a sequence of inputs,” we are generating “all possible decompositions of a sequence of inputs.”

Generating Trees

This is a non-trivial task. There are solutions for a sequence of a given length. But I am more interested in an incremental solution where you don’t know the length of the sequence in advance. Let’s consider various cases:

  • For an empty sequence of inputs, no binary trees are possible.
  • For the first input, for example a, a tree consisting of a terminal is possible. I’ll simply write this tree as a.
  • For the second input, for example b, a tree consisting of a nonterminal, with the two inputs as its children, is possible. I’ll write this tree as (a b) The parentheses signal the presence of a nonterminal with the children between them.

For more than two inputs, things get complicated.

  • For a sequence of three inputs, two trees are possible: (a (b c)) and ((a b) c)
  • For a sequence of four inputs, five trees are possible: (a (b (c d))), ((a (b c)) d), (a ((b c) d)), ((a b) (c d)), and (((a b) c ) d)

You can see that the idea is to “connect” an input to, or “pair” an input with its prior (left) or subsequent (right) neighbor at different times during the construction of the neighbor. In the most “eager” case, we pair every input with its left neighbor immediately and get a tree like (((a b) c) d). In the most “lazy” case, we pair every input with its right neighbor, if there is one. This means we must wait to do any connections until the last input is read. This gives us a tree like (a (b (c d))).

Every time we get an input, there is a choice of being eager or lazy. A different sequence of choices will result in a different tree, so all possible sequences must be generated. This means that for intermediate inputs, we need to “split” the state of the tree generation to represent both choices.

An Algorithmic Approach

A stack is a suitable data structure in which to store a sequence of choices. Our approach will be to create multiple stacks representing different sequences of choices in tree generation:

  • We will start with a single empty stack
  • For the first input, we will create a terminal and put it on top of the stack for later use. This represents the choice to be lazy. (There is no possibility to be eager with the first input because there is no prior input to pair with.)
  • For any subsequent input, we will create a terminal for the input and a copy of the stack. The original (“lazy stack”) will represent the choice to be lazy for this input. The copy (“eager stack”) will represent the choice to be eager.
    1. We will put the new terminal on top of the lazy stack.
    2. We will pop a prior tree off the top of the eager stack, and create a nonterminal combining the tree and the new terminal
    3. With this new nonterminal, too, there is a choice to be eager or lazy. So we will create a copy of the popped stack. The original will represent the choice to be lazy. The copy will represent the choice to be eager, so we will do the above iteratively until we cannot pop any more trees off the stack.
  • For the second input, we will end up with two stacks. For additional inputs, we will do the above for all the stacks.

Once the last input is processed as described above, there will be a large number of stacks:

  • Some will have multiple trees stacked on them. These were created in anticipation of additional input that would pair the trees. These stacks can be filtered out.
  • The remainder will have a single binary tree on top, representing a different sequence of decisions. These will be the possible binary trees on the input.

This process is illustrated below for four inputs. Commas separate trees on a stack. Grey lines trace which stacks are copies of which other stacks.

Implementation in Rust

We can try to represent a binary tree data structure corresponding to characters in Rust as follows:

enum BinaryTree {
    Terminal(char),
    Nonterminal(BinaryTree, BinaryTree)
}

Unfortunately, this causes the compiler error recursive type BinaryTree has infinite size.

The reason is that when a function creates a local variable of type BinaryTree, Rust needs to know its size at compilation time so it can be put on the stack.

The compiler suggests storing references to other binary trees, because the size of any reference is known at compilation time:

enum BinaryTree {
    Terminal(char),
    Nonterminal(Box<BinaryTree>, Box<BinaryTree>),
}

At the top level, we have a function that borrows a string (because it won’t need to modify it), generates stacks, filters them, and returns the top of the remaining stacks.

fn generate(input_sequence: &str) -> Vec<BinaryTree> {
    tops(filter_stacks(generate_stacks(input_sequence)))
}

Stacks are represented using Rust’s standard Vec type, which supports push and pop operations as you would expect a stack to support:

struct Stack(Vec<BinaryTree>);

The generate_stacks function uses the chars method to acquire a character iterator on the input string. Iterator types have a powerful method, fold. The idea of fold is to “fold” all elements of the iterator into some result, which can be of any type. fold takes two arguments:

  • an initial value for the result (which would be returned if the iterator was empty)
  • a closure or function. This must accept two arguments: the current value for the result, and the next element from the iterator. It must return an updated value for the result.

(A similar method, reduce, is more restrictive. You need not provide an initial value, because it uses the first element as the initial value. However, because the iterator might be empty, reduce returns an Option of the same type as the iterator.)

By using fold wherever possible, you will find that your code becomes more comprehensible, better organized, and more amenable to parallel processing.

In the case of generate_stacks, the result to generate is a list of stacks.

The closure, in turn, acquires an iterator on the current list of stacks and folds it into a new list of stacks. The function used in this fold is generated at run-time by a higher-order function lazy_eager_fn which takes the current character as input.

fn generate_stacks(input_sequence: & str) -> Vec<Stack> {
    input_sequence.chars().fold(
        vec![Stack::default()],
        |stacks, input| {
            stacks.into_iter().fold(
                Vec::default(),
                lazy_eager_fn(input)
            )
        }
    )
}

lazy_eager_fn returns a function that takes the list of stacks being generated and one of the prior stacks generated from the previous input. Based on the “eager” choice, multiple stacks may be added to the list, so the work of generating them is delegated to eager. Based on the “lazy” choice from the prior stack, a new stack is added to the list with a terminal containing the current input.

fn lazy_eager_fn(current: char) -> impl Fn(Vec<Stack>, Stack)
-> Vec<Stack> {
    move |mut new_stacks, mut stack| {
        // eager may produce multiple stacks
        new_stacks.append(& mut eager(stack.clone(), current));
        // lazy
        stack.0.push(BinaryTree::Terminal(current));
        new_stacks.push(stack); // transfer ownership
        new_stacks
    }
}

Recall that eager must pop trees off the stack iteratively. For this reason, we define a new method on a Stack called popping_iter which consumes (takes ownership of) the stack and returns an PoppingIterator for it. The PoppingIterator implements the Iterator trait. Each of its elements is a tuple consisting of a stack element and a copy of the stack that element was just popped off.

struct PoppingIterator(Stack);

impl Iterator for PoppingIterator {
    type Item = (BinaryTree, Stack);

    fn next(&mut self) -> Option<Self::Item> {
        self.0.0.pop().and_then(|tree| Some((
            tree, // The tree that was just popped off the stack
            self.0.clone(), // Copy of the stack after pop
        )))
    }
}

impl Stack {
    fn popping_iter(self: Self) -> PoppingIterator {
        PoppingIterator(self)
    }
}

The tuples returned by the PoppingIterator can now be folded into a new list of stacks. However, a nonterminal must also be updated in every iteration. So eager starts with an initial tuple consisting of an empty list of stacks, and a terminal for the current input. In every iteration, the list of stacks (initially empty) is updated and the binary tree (initially a terminal for the current input) gets updated.

You can see that for the first input, the PoppingIterator immediately returns None because the stack is empty. eager returns an empty list of stacks. It is as if lazy_eager_fn only created a lazy version of the stack, which is the behavior we want.

fn eager0(new: (Vec<Stack>, BinaryTree), popped: (BinaryTree, Stack))
-> (Vec<Stack>, BinaryTree) {
    let mut new_stacks = new.0;
    let new_tree = new.1;
    let tree = popped.0;
    let stack = popped.1;
    let new_nonterminal = BinaryTree::Nonterminal(
        Box::new(tree),
        Box::new(new_tree),
    );
    let mut new_stack = stack;
    new_stack.0.push(new_nonterminal.clone());
    new_stacks.push(new_stack);
    (new_stacks, new_nonterminal)
}

fn eager(stack: Stack, current: char) -> Vec<Stack> {
    stack.popping_iter().fold(
        (Vec::default(), BinaryTree::Terminal(current)),
        eager0
    ).0
}

Once stacks have been generated for all of the inputs, filter_stacks returns the ones with a single element:

fn filter_stacks(stacks: Vec<Stack>) -> Vec<Stack> {
    stacks.into_iter()
        .filter(|stack| 1 == stack.0.len())
        .collect()
}

tops returns the binary trees on the top of those stacks:

fn tops(stacks: Vec<Stack>) -> Vec<BinaryTree> {
    stacks.iter()
        .map(|stack| stack.0[0].clone())
        .collect()
}

Once trees are generated, they can be printed out by implementing the Display trait for BinaryTree. The main function prints out the 14 trees for the sequence abcde.

impl Display for BinaryTree {
    fn fmt(&self, f: &mut std::fmt::Formatter<'_>) -> std::fmt::Result {
        match self {
            BinaryTree::Terminal(c) => write!(f, "{c}"),
            BinaryTree::Nonterminal(left, right) =>
                write!(f, "({left} {right})"),
        }
    }
}

fn main() {
    let x = generate("abcde");
    println!("{} trees", x.len());
    for t in x {
        println!("{}", t);
    }
}

14 trees
((((a b) c) d) e)
(((a b) c) (d e))
((a b) ((c d) e))
(((a b) (c d)) e)
((a b) (c (d e)))
(a (((b c) d) e))
((a ((b c) d)) e)
(a ((b c) (d e)))
(((a (b c)) d) e)
((a (b c)) (d e))
(a (b ((c d) e)))
(a ((b (c d)) e))
((a (b (c d))) e)
(a (b (c (d e))))

This version of the full code is here.
